R V Industries is a leading stockist and exporter of premium sheets and plates in India and globally. Our extensive inventory features a diverse range of stainless-steel sheets and plates in multiple grades, such as 304, 316, 321, and 347, as well as mild steel and Boiler Quality (BQ) plates in grades like IS 2062 and ASTM A516. Our products are widely utilized across key industries, including the chemical industry, power plants, oil and gas sector, and pharmaceutical industry, reflecting our dedication to meeting the specific demands of each sector.
We also specialize in offering sheets and plates in different grades including Nickel Alloy 200 Sheets & Plates, Hastelloy C22 Sheets & Plates, Monel K500 Sheets & Plates, Inconel 625 Sheets & Plates, and Titanium Grade 5 Sheets & Plates, among others. As a top-tier stockist in the industry, we are committed to delivering high-quality sheets and plates to clients across various international markets. Our Sheet & Plate undergoes various types of testing such as Corrosion Testing, Hardness Testing, Heat Testing and Visual Inspections so that our clients receive premium quality Sheet & Plate.
Standards, Grades and Specification of Sheet & Plate
Specification of Sheet & Plate with its Grades, Size and Dimension highlighted in the table below.
| Specification | |
|---|---|
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Available Types of Sheet & Plates
Different types of available Sheet & Plate define below.
Chemical Composition of Sheet & Plate
Chemical Composition of Sheet & Plate with its Grades define in the table below.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. max. | - 0.08 | - 2.0 | - 0.75 | - 0.045 | - 0.030 | 18.0 20.0 | - | 8.0 10.5 | - 0.10 |
| 304H | min. max. | 0.04 0.10 | - 2.0 | - 0.75 | -0.045 | - 0.030 | 18.0 20.0 | - | 8.0 10.5 | |
Mechanical Property of Sheet & Plate
Mechanical Property of Sheet & Plate with its Density, Tensile Strength and Elongation define in the table below.
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
| 304H also has a requirement for a grain size of ASTM No 7 or coarser. | |||||
